SEH Series End Suction Centrifugal Pump
SEH Series End Suction Centrifugal Pump

SEH Series End Suction Centrifugal Pump

End suction centrifugal pump for water supply, fire fighting, HVAC, and irrigation systems

Model Series: SEH Series
WhatsApp for Quote

SEH Series End Suction Centrifugal Pump

The SEH series features end suction back pull-out configuration with close impeller, providing a robust and compact design that reduces downtime and maintenance costs. Engineered with precision hydraulics for high efficiency and reliable performance.

Design Features

  • End suction back pull-out configuration for easy maintenance
  • Compact design with minimal parts for structural rigidity
  • Heavy duty bearing assembly with oil/grease lubrication options
  • Advanced oil circulation system with labyrinth rings
  • Robust shaft design minimizing deflection at stuffing box

Sealing Options

  • Standardized easy-to-install seal-sleeve options
  • Wide range of custom seal types available
  • Mechanical seals for demanding applications
  • Gland packing for cost-effective operations

Technical Specifications

Flow Rate: Up to 500 m³/h
Head Range: Up to 100 meters
Temperature Range: Up to 120°C
Pressure Range: Up to 16 Bar
Power Range: 0.5 kW to 160 kW

Key Features

Engineered with precision hydraulics for high efficiency and reliable performance
Compact design and minimal parts provide strong structural rigidity
Multiple material options enable wider application coverage
Flexible seal & bearing combinations for diverse operating environments
Every part designed for hassle-free maintenance and lower cycle costs
End suction back pull-out configuration reduces downtime

Materials of Construction

Component Standard Material Optional Materials
Volute Casing Grey Cast Iron EN-GJL-250 Stainless Steel 1.4408 / Bronze CC480K-GS
Impeller Grey Cast Iron EN-GJL-250 Stainless Steel 1.4408 / Bronze CC480K-GS
Shaft Stainless Steel 1.4408 SS410
Stuffing Box Grey Cast Iron EN-GJL-250 Stainless Steel 1.4408 / Bronze CC480K-GS
Bearing Bracket Grey Cast Iron EN-GJL-250
Shaft Sleeve Stainless Steel 1.4408 SS410
* Specific Materials of Construction (M.O.Cs) available on request

Typical Applications

HVAC Systems
